Not connected.
Tap Connect and pick your controller (“JMB one #ID-XXXX”).
Chrome/Edge only — on iPhone use the Bluefy browser. Bluetooth on.
Browse every tab with example data — no controller needed.
Nothing you tap is sent anywhere.
DEMO — example data, not a live controller.
Live DMX in control
is driving the outputs — manual colour, dimmer
and effects here are overridden until the signal stops.
RGB 100% · FX speed 50% · dimmer 0%
Hue/Sat and Kelvin are two ways of choosing — the last
column you touch wins. ΔUV tints green (+) or magenta (−). Applies as
manual colour to the selected ports.
Recall crossfades to the scene over the fade seconds
(0 = snap), always over that time from any state. Effects fade out (and
in) through a dip rather than snapping. Tap a scene's name to rename it.
Scenes live in this phone's browser.
DMX signal
no signal
—fps
—slots
—start code
—last packet
—ASC pkts
—errors
Universe analyzer
Universe
tap a cell — channel, level, captured range
Flicker finder
Arm it, then every
channel-value change on the wire is logged here — the 2am ghost-flicker
catcher. Survives leaving this tab.
RDM universe
Discover and edit every RDM fixture on the
thru line — address, personality, label, identify and sensors, like a
RDM tester. Scanning takes over the output line while active.
Port bus
on screens, BLE name (next boot), RDM label
how base addresses fan out
s
keep last look after DMX loss · 0 = forever
—
Link pairs with a transmitter that's in linking mode
(e.g. Aurora); Unlink forgets it. Status is data-truth: "linked — no data"
means paired but the transmitter isn't sending.
—
receive sACN / Art-Net over Wi-Fi
match the console's output universe
A lighting console (or an Art-Net node) on the same Wi-Fi
router streams the universe here — no DMX cable to the fixtures. Wired DMX
still works and out-prioritises the network on a tie.
dim a hot port instead of tripping
Thermal foldback eases a port down over the last 10°C
before its trip so it rides through instead of hard-latching.
Sets a look on this unit and every armed unit down
the DMX line. Arm each downstream unit first on its panel: menu → Setup →
Chain Listen → ARMED. Deploy from the first controller in the chain.
BPM
Tap 4+ times in time with the music, or
type a BPM. 128 = the designed tempo. Beat effects (Party, Club, Pulse)
follow it rig-wide, and the ports' Speed wheels move with it.
Spread offsets each port in time so effects sweep across
the rig as a wave.
Everything: ID, curve, apply mode, all port patch +
looks + effects, and this phone's scenes — one shareable file.
—
Update the controller over Bluetooth — pick your
build's
firmware.bin. Keep the app open and the phone unlocked
until it finishes; the controller reboots into the new firmware itself.Flash strobes this controller's screen “HERE” for
3s (outputs untouched) — tap it after connecting to check you're on
the right unit.
The Bluetooth name is what you see when connecting.
It changes at the controller's next restart.
